Description
Motor Application:
Fan coil
The indoor unit of ceil aircon
Central aircon
EVEs
Commercial air curtain machine.
Sterilization equipment.
Product Features:
Pure copper winding motors.
Use NSK low noise high-quality rolling bearing.
Nickel plating for shaft, electrophoretic coating for the enclosure.
Insulation class E/B/F, protection class IP00~IP54.
Reasonable structure, high efficiency, low-temperature rise, low noise, small vibration.
Technical Parameters:
| Model Number | Voltage
/V |
Frequency
/Hz |
Power
/W |
Current
/A |
Speed
/RPM |
Capacitance
/uF |
| YDK110-8-6 | 220-240 | 50/60 | 8 | 0.12 | 700/560/450 | 1.2 |
| YDK110-10-4 | 220-240 | 50/60 | 10 | 0.15 | 750/600/480 | 1.2 |
| YDK110-16-4 | 220-240 | 50/60 | 16 | 0.17 | 800/640/510 | 1.5 |
| YDK110-20-4 | 220-240 | 50/60 | 20 | 0.23 | 850/680/540 | 2.0 |
| YDK110-25-4 | 220-240 | 50/60 | 25 | 0.27 | 880/700/560 | 2. |
