Description
Motor feature:
1. Being adapted internationally famous qualified low noise ball bearing, it makes motor long life and no need for more oil supply.
2. High waterproof grad.
3. Customized aluminum shell, high efficiency, low noise.
4. It adopts high-quality thermoset encapsulation materials.
Motor application:
1. Different kinds of ventilation equipment.
2. Central air conditioner outdoor fan.
3. Insulation class E/B/F, protection class IP20~IP54.
4. Bearing: rolling bearing, NSK low noise high-quality material.
| Product Type | Ventilation Equipment Motor |
| Applications | - Different kinds of ventilation equipment - Central air conditioner outdoor fan |
| Shell Material | Iron or Aluminum (varies by model) |
| Insulation Class | E/B/F |
| Protection Class | IP20~IP54 |
| Bearing Type | NSK low noise high-quality rolling bearing |
| Features | - Long life with no need for additional oil supply - High waterproof grade - High efficiency, low noise - High-quality thermoset encapsulation materials |
Motor specification - Iron Shell Series:
| Type | Shell | Power | Frequency | Voltage | Speed | AMPS (A) |
|---|---|---|---|---|---|---|
| YDK100-6 | Iron | 100W | 50Hz | 220V | 850/700 | 0.85 |
| YDK150-6 | Iron | 150W | 50Hz | 220V | 800/600 | 800 |
| YDK-200-6 | Iron | 200W | 50Hz | 220V | 830/600 | 830 |
| YDK-270-6 | Iron | 270W | 50Hz | 220V | 630/400 | 630 |
| YDK-380-6 | Iron | 380W | 50Hz | 220V | 680/400 | 680 |
| YDK-450-6 | Iron | 450W | 50Hz | 220V | 1000 | 1000 |
| YDK-550-6 | Iron | 550W | 50Hz | 220V | 900 | 900 |
Motor specification - Aluminum Shell Series:
| Type | Shell | Power | Frequency | Voltage | Speed | AMPS (A) |
|---|---|---|---|---|---|---|
| YS-250-6 | Aluminum | 250W | 50Hz | 380-415V | 925 | 0.9 |
| YS-370-6 | Aluminum | 370W | 50Hz | 380-415V | 925 | 1.3 |
| YS-550-6 | Aluminum | 550W | 50Hz | 380-415V | 925 | 1.4 |
| YS-750-6 | Aluminum | 750W | 50Hz | 380-415V | 720 | 2.5 |
| YS-120-8 | Aluminum | 120W | 50Hz | 380-415V | 925 | 1 |
| YS-370-8 | Aluminum | 370W | 50Hz | 380-415V | 720 | 1.5 |
| YS-550-8 | Aluminum | 550W | 50Hz | 380-415V | 710 | 2 |
| YS-750-8 | Aluminum | 750W | 50Hz | 380-415V | 710 | - |
