Description
Application:
1. Portable air conditioner, movable air conditioner, mobile air conditioner
2. Window air conditioner
3. Commercial air conditioner
4. Air curtain
5. Fresh air ventilation
Benefits:
1. Low noise
2. High efficiency
3. Reliable
4. Low vibration
| Product Type | Air Conditioner Motor |
| Applications | - Portable/movable/mobile air conditioners - Window air conditioners - Commercial air conditioners - Air curtains - Fresh air ventilation |
| Benefits | - Low noise - High efficiency - Reliable - Low vibration |
| Frame Size | Φ140 |
| Voltage Options | 208-230VAC/115VAC/460VAC |
| Frequency | 60Hz |
| Pole Options | 4, 6 pole |
| Insulation Class | E, B, or F |
| Customization | Dimensions and parameters can be customized according to customer requirements, OEM/ODM offered |
Parameters:
Note: Listed are representative motors, only for reference, dimensions and parameters can be customized according to customer requirements, OEM/ODM offered.
| Model Number | Voltage (V) | Frequency (Hz) | Power | Speed (RPM) | Rotation | Capacitor (MDF/VAC) | OEM Model |
|---|---|---|---|---|---|---|---|
| YSK140-375-6A | 208-230 | 60 | 1/2HP | 1075 | REVERSIBLE | 10/370 | 5KCP39MGK209T |
| YSK140-375-6A3 | 208-230 | 60 | 1/2HP | 1075/3 SPD | REVERSIBLE | 7.5/370 | FASCO D703 |
| YSK140-375-6A7 | 208-230 | 60 | 1/2HP | 1075 | REVERSIBLE | 10/370 | 5KCP39PGG404ET |
| YSK140-375-4A9 | 208-230 | 60 | 1/2HP | 1625/3 SPD | REVERSIBLE | 5/370 | PM3102186 |
| YSK140-375-6A10 | 208-230 | 60 | 1/2HP | 1075 | REVERSIBLE | 5/370 | PM3102185 |
| YSK140-375-6A11 | 460 | 60 | 1/2HP | 1075 | REVERSIBLE | 5/370 | PM3102184 |
| YSK140-375-4A12 | 208-230 | 60 | 1/2HP | 1625/3 SPD | REVERSIBLE | 7.5/370 | FASCO D784 |
| YSK140-375-4A13 | 208-230 | 60 | 1/2HP | 1625 | REVERSIBLE | 7.5/370 | FASCO D788 |
| YSK140-375-4A14 | 115 | 60 | 1/2HP | 1625/3 SPD | REVERSIBLE | 15/370 | FASCO |
