Maximum working pressure ¹
33, 45
Temperature range
-20°C — 130°C
Receiver volume
45.0
Diameter (ØD)
324
Length
630
Liquid Refrigerant Receivers designed to Hold Excess Liquid That ...
General tolerances [mm]
/ -3
Dimensions (see drawing)
D: ф219mm; L: 497mm; L1: 130mm; L2: 200mm
Volume
16 l
Test pressure [PT]
48 bar
The diameter of the mounting flange
205 mm
Inlet
5...
Maximum working pressure – 33 bar
Shell diameter – 273 mm
Shell length – 900 mm
Total volume litre – 45 litre
Total volume m3 – 0.045 m3
Holding capacity R404a at 80% at 32c – 36.28 Kg
Inlet connec...
